User Variables (V# Variables)
RTL User Text Variables (T#
Every symbol has up to 512 available User Variables
(V#1, V#2, ... V#512) which can be used to store data specific to that
symbol. User Variables have become useful in a variety of ways in
Investor/RT. As quotepage columns, their values can be adjust
manually directly in the quotepage cell. Values can be set for an
entire quotepage with a single scan (e.g. SET(V#1, CCI)). Reference
lines can be attached to user variables. Each variable can be
assigned it's own custom title (which shows up in quotepage columns) and
display format (2 decimal, 32nds, etc). Variables values can be
displayed in chart annotations. Custom Columns can be setup to
dynamically feed their value directly into any user variable. All
user variables are saved on the database and retain when restarting the
program. User variable values can be imported from external text
Below are some additional details on User Variables,
taken from the What's New documentation.
Display Format Improvement
The Setup: Preferences: User Variables
window now provides a new display format for user V# variables, called
"Instrument" format. Instead of a fixed format for the user
variable, any user variable can now be setup to use instead the display
format of its associated instrument. When a V# variable has this format,
the numeric values displayed in the quotepage column for that V# will be
shown using the price format of the instrument for each row. Chart
annotations that include %V#n in the annotation text will similarly
display V# values using the instrument display format of the instrument
associated with the annotation. During backtesting the Show and Note
command output will be similarly affected for V# variables setup this way.
Adjusting V# Column
Properties in a Quote Page
If you have one or more V# user variable as columns in a quote
page you can easily adjust the column title or the precision of the display
format by right-clicking on any cell in the V# column. Macintosh users
control-click. This takes you to the Setup: Preferences: User Variables
window for that V# user variable. Make the adjustments and click OK. The
quote page will then reflect the changes.
All User Variables Saved in
Prior to Version 5.5, users variables V#1 through V#6 were the
only user variables whose values were kept permanently in the Investor/RT
database. All other user variables were considered "temporary" and their
values were set to zero each time Investor/RT started. In Version 5.5, all
user variables, V#1 through V#512 are retained on the Investor/RT database
so you can now rely on these values being retained when you quit the
Importing V# Values Using
The Import facility (File Menu) has been enhanced to allow values for any V#
user variable to be imported. For example, externally acquired fundamental
data or calculated data of any kind could be imported in this fashion. Then
the imported V# values for each instrument can be used in scans, custom
indicators, signals, etc. Use the "Current Quotes" option when importing.
Create a "Format" that includes the ticker and the V# variables to be
imported. Note that at present only V#1 through V#6 values are retained
permanently for each instrument on the database when Investor/RT quits.
Thus, values imported for other V# variables must be re-imported when
Investor/RT starts up again. In fact, you could use the import format to
open the .all symbols quote page in this format, then save the page as text.
This will save the ticker and each V# value to a text file that can be
easily imported at any future time those values are needed for some purpose.
Note that "exporting" V# values is not accomplished using File: Export.
File: Export is for exporting historical data of any periodicity. File:
Save: Save as Text is used to save a quote page of instrument data as a text
file. Saved quote page text files can be imported using File: Import.
Data values from outside sources for each ticker can now be
imported into user assigned V# variables so that the data can be used for
reference in quote pages, scans, etc. The data values must be numeric data.
To import numeric values simply setup a format using Setup: Formats. For
example, support you had a text file in the following format:
AAPL,1.11,2.22,3.33 IBM,4.44,5.55,6.66 MSFT,7.77,8.88,9.99 Etc.
Each line in the file in this example contains a ticker symbol followed by
three numbers, all fields separated by commas (or tabs). Setup a format and
name it "Import Three Numbers". The format could be "ticker, V#1, V#2, V#3"
for example. Then use File: Import to import the data. Specify "Current
Quotes/Other Data" as the Import Type. Specify "Import Three Numbers" as the
format to use. When you import the data, variable V#1 will receive the value
1.11 for AAPL, 4.44 for IBM, and 7.77 for MSFT.
Note that the Import format you use can include any V# variables, V#1
through V#512. However, only V#1 through V#6 are saved permanently on the
database when you Quit Investor/RT. V#7 through V#512 can be used as
temporary variables for holding imported data, but these variable are reset
to zero when you quit.
If you want to preserve the value of V# variables higher than V#7 when you
quit, simply create a quote page format containing the ticker followed by
V#1 variable columns you wish to preserve. Open the .All Symbols quote page
and put the .All Symbols page into this format. Then Issue the File: Save as
Text command to save all of the data as a text file. This text file can be
imported back into Investor/RT at a later time using File: Import as
described above. The format you used to "Save as Text" is the format you
should specify when you import. Thus, this new capability to import V#
variables makes it possible to extend Investor/RT to save all of your V#
variables permanently with a little setup work.
Testing Multiple Custom
Each custom column, whether it references a built-in column, a
scan or signal, a custom indicator or a technical indicator has a value for
each instrument that changes over time. Scans and trading signals are
true/false expressions that have a numeric value of 1.0 (true) or 0.0
(false). If you want to make the calculated value of some custom column
available to other scans/signals/custom indicators (and hence to other
custom columns) then you can specify a V# user variable for the custom
column using the "Calculation" tab of the Custom Column setup window.
Suppose, for example you had three custom columns each showing some moving
average. You could use, say V#10 for one moving average column, V#11 for
another, and V#12 for the third one. The values for V#10, V#11, and V#12
will change dynamically as the custom columns are recalculated. Thus, you
can rely on these value to create a custom indicator such as:
(CL > V#10) + (CL > V#11) + (CL > V#12)
Make another custom column to show the value of this custom indicator. The
formula will evaluate to 3 if an instrument's last price is above all three
moving averages, 2 if above only two moving averages. A zero value indicates
the last price is below all three moving averages. Rules for each value
0,1,2, and 3 can then color code the custom column. Notice there is very
little processing involved in evaluating this custom column since all of the
moving averages are pre-calculated and available via the V# user variables.
This is a very powerful mechanism. Any custom column calculation can
essentially pass its results using a user variable to any other column,
which in turn considers the V# variable in it's own formula. Note that the
calculation order of cells for each row in a quote page is left to right,
thus the custom columns should be arranged in such a way that any dependent
columns be to the right of the column(s) that produce the V# results it
needs. Note also that any custom indicator or scan/signal can also include
SET statements in their formulas. User variables set in this fashion are
similarly available to other calculations going on in other custom columns
within any open quote pages.
Prior to version 5.0, there were a limited number of V# variables (user
variables) for use in scans and trading signals, and some technical
indicators. The number of user variables in Version 5.0 is now a user
preference in Setup: Preferences: User Variables. The minimum number of user
variables is six, V#1 through V#6. The maximum number is 512, V#1 through
V#512. Each user variable can be given a name (used in quote page column
titles) and a display format. It is recommended that you quit Investor/RT
and start again when you increase the number of user variables. Memory usage
for user variables is now dynamic. This means, for example, if you specify
100 user variables and you are tracking say 300 symbols, the memory space
used to hold the V# data is allocated only as needed. User variables can be
set by editing the variable's cell in a quote page or by using a SET
statement in a scan. So if you run a scan to SET(V#100, ...) and the scan
looks at 50 of your 300 symbols, memory for user variables is allocated only
for those 50 symbols. Note that V#1 thru V#6 are always allocated for every
symbol. These first six user variables are "persistent", that is, they
retain their values after quitting and starting Investor/RT again. Various
menus and lists in Investor/RT that display V# variable choices have all
been enhanced to show the V# variables called for in Setup: Preferences:
Custom Instrument Enhanced
Components of custom instruments can now make reference any V# variable.
Choices for the "Price" value used in a custom instrument component now
include all V# variables. This enhancement opens up literally any user
defined computation to tracking as an instrument using references to V#
variables. By setting up a scan to periodically calculate some V# variable
for one or more instruments, you can then define a custom instrument that
sums the V# values for the instrument(s) and track the resulting summation.
Naming V# Column Headings
A new facility has been added to Setup: Preferences to permit the
user to provide column headings and numeric displays format preferences for
each of the twenty V#n variables available in the RTL Language. Choose
Setup: Preferences: User Variables. Pick a particular V# variable, enter a
column heading and adjust the display format for that V# variable. Click
Apply to save the changes and leave the window open for further changes or
click OK to save the changes and close the window. It is recommended but not
required that you include the V# variable's name as part of the column
title. For example if you use V#9 as an exponential moving average then you
could assign it a column heading of "V#9-Exp MA" or "Exp MA V9". This
assures that you easily see which V# variable is used for each column.
V# Variables In Portfolios
V#n variables are now available for display as columns in
portfolios as well as quote pages. To add a column to a portfolio,
right-click (control-click if Mac) on any column heading and pick "Add New
Column" from the popup menu. The twenty V# variables are all listed (under
V) in the alphabetical list of available columns. The current column title,
if assigned, will be shown in the list of columns as well. Note that at most
30 columns can be present in a portfolio (or quote page) so you may have to
remove an unneeded column before you can add a new one.
V# Variables User Editing
When a V# user variable is present in either a quote page or portfolio, the
numbers are editable. This enables you to use V# variables for user entered
values, e.g. a hand-entered "target price". This opens up lots of new
possibilities for scans that incorporate V# variables, reference lines based
on V# variables, etc. Formerly, V# variables could take on a value only when
the V# variable was the subject of a SET command in a scan.
Horizontal reference lines can be based on RTL-calculated values
The horizontal reference line technical
indicator has been enhanced to allow the reference line to be pegged to any
of the twenty V# user variables in the RTL language. See the discussion of
Pivot Point above. Another example would be to use a scan to set a V#
variable to a moving average calculated using Daily data and then setting up
a reference line in an intra-day chart to draw at the price level set into
the V# variable. To setup a reference line this way, check the radio button
titled "Use" and choose the V# variable from the list provided. Using an
auto-scan, the value of a V# variable can be calculated periodically during
the trading session, causing the reference line to move accordingly as the
value of the V# variable changes.
improvements made to "Rule Price"
To provide additional user flexibility menu choices for "user variables" V#1
through V#20 have been added as "Rule Price" options. What this means is
that trading rules can set the value one or more V# variables and a
particular V# variable can be used as the rule price to enter or exit a
position. When a V# variable is used as an entry or exit price is a rule,
Investor/RT will check to see if the value of the V#1 is between the high
and low extremes for the particular bar when the rule is being tested. If so
the V#1 variable will be used "as is". If the V# variable is higher than the
high of the bar, then the high price of the bar will be used in space of the
V# variable. Similarly if the V# variable is lower than the low of the bar,
the low will be used to enter or exit the position.
New RTL Tokens for Calculating
QuotePage Custom Columns
There are now twelve quote page columns (named
V#1, V#2, V#3, ..., V#12) designated as user-defined variables. V#7 through
V#12 are new in version 4.3. These are columns whose value for each
instrument can be calculated and set using a scan, a trading signal or a
custom indicator. Tokens having the same names have been added to the RTL
Language for referencing the current value of these variables. The first six
variables have the property that the calculated values are retained in the
Investor/RT database. The second group of six (V#7 through V#12) are
temporary variables whose values are set to zero each time Investor/RT
starts up. The SET command can be used to set the value of a variable to any
user-specified formula. For example, the RTL scan request:
SET(V#1, HIALARM - CL)
Sets the value of V#1 for each scanned instrument to the amount each issue
is currently trading from its high alarm value. Since the variables V#1 -
V#12 are sort fields, the scan can also "rank" the quote page, showing you
which issues are closest to their alarm levels. Unlike normal calculated
values in scans, the values for V#1 thru V#6 are permanently maintained (on
the database) for each instrument. The values are saved when you quit
Investor/RT. These new columns are available for display in any quote page,
not just the quote pages produced by scans. The displayed values for V#1 -
V#12 will always reflect the results of the most recent RTL calculation that
set the value. The RTL variables may be referenced by several scans (or
trading signals) in succession. One scan sets the value of a variable for
each instrument. Subsequent scans or trading signals base their results on
the value of one or more variables calculated earlier. Using the "auto scan"
method, a particular calculation of interest to the user could be performed
at some periodic interval and the most recently calculated values for each
instrument can be displayed in any quote page.
Historical Data for RTL Calculations
The SET command in the RTL language provides a means of setting any
calculated value into a custom variable V#1 through V#12 (see item #1
discussion above). These values can be viewed by adding the appropriate V#
columns to your quote pages.
Investor/RT Version 4.4 provides a new twist to the use of V# variables: a
method for recording the results of any such calculation historically. This
new capability is best explained by way of example. Suppose you want to
track the tick velocity (ticks per minute) for some instrument or group of
instruments. This can be done by running an auto scan to periodically
calculate the TV (tick velocity) indicator. The scan formula would be
TV > 0
Using one of the new custom variables you can revise the scan to read:
Running this scan periodically with auto-scan (say once a minute) causes the
V#1 data column in any open quote pages to update dynamically for each
scanned instrument. The V#1 quote page column shows the tick velocity of
To inform Investor/RT that you wish to record the values of tick velocity
over time, you must define a special instrument to Investor/RT having a
ticker symbol in a prescribed format. The purpose of the special instrument
is to "hold" the collected data. The ticker symbol must have the format: "xxxx(V#n)"
where xxxx is a valid ticker symbol and n is a number from 1 to 12. For
example "INTC(V#1)" would be the ticker of a special instrument that tracks
the values of V#1 for INTC over time. Each time Investor/RT executes a
SET(V#1, ...) command for INTC, the computed value that is "set" into V#1 is
used generate a "tick" for the ticker symbol INTC(V#1).
The ticker symbol "INTC(V#1)" is just like any other instrument in
Investor/RT. You can chart it, view it in a quote page or quick quote
window, or view each tick in a time and sales window if you like. All of the
charting facilities of Investor/RT can be used to watch INTC(V#1) throughout
the trading session. You can view technical indicators on INTC(V#1), e.g.
add a moving average to the INTC(V#1) chart so see a smoothed tick velocity
In summary, the "Auto Scan" feature of Investor/RT in concert with the SET
command causes updates to occur on any special instrument you have defined.
This is a very powerful new capability. An auto scan can be used to
calculate several V#n variables periodically while the instruments with
ticker format "symbol(V#n)" are used to track the results intra-day. For
SET(V#1, TV) and SET(V#2, CL/CL(INDU)) and
This scan calculates the tick velocity and the price of an issue relative to
the Dow Jones Industrial Average and the S&P 500 Index. For any symbol
scanned you can create the tickers symbol(V#1), symbol(V#2) and symbol(V#3)
to track the intra-day values of the three V# variables.
